Dahua 24-inch Full-HD LED Monitor
Model: DHI-LM22-C200
- The 1920*1080 resolution produces clearer and more vivid pictures;
- Wide colour gamut, 99% sRGB, 85% NTSC, 85% DCI-P3, 85% Adobe RGB. It meets the designer’s demand of image texture;
- 178°H/178°V extra-wide viewing angle for all-round viewing performance;
- Adaptive sync can effectively solve picture lagging and tearing problems;
- Low blue light technology can support a comfortable viewing experience;
- 3000:1 high static contrast ratio makes more obvious contrast between bright and dark.
Downloads:
Specifications
| Model | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Model | DHI-LM24-C200 | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Display | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Screen Size | 23.8″ | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Panel type | VA | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Aspect Ratio | 16:9 | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Resolution | 1920×1080 | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Backlight | E-LED | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Brightness/Luminance | 250nits(typ) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Contrast Ratio | 3000:1 | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Color Support | 99% sRGB, 85% NTSC, 85% DCI-P3, 85% Adobe RGB | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Viewing Angle(H/V) | 178°(H)/178°(V) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Response time | 5ms(OD) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Refresh Rate | 75Hz | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Signals | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Interface | VGA×1,HDMI 1.4×1,Audio out×1 | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| General | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Power Supply | DC 12V 2.5A | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Power Type | Adapter | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Consumption (Standard) | 20W(typ) 31W(max) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Consumption (Standby) | <0.5W | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Net Weight | 3.3kg | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Gross Weight | 4.5kg | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Tilt Angles | -5°±2°/15°±2° | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Swivel(angle) | N/A | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Pivot(angle/direction) | N/A | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Height Adjustment | N/A | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| VESA | 75x75mm | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Dimension(W×H×D) | 542.4*334.5*36.5mm(without stand) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Package(W×H×D) | 620*410*110mm | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Work Environment | Temperature | 0°~40°(32°F~104°F) | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Humidity | 10%~85% | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Accessory | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Standard | HDMI cable, Adapter, Stand, Base | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
