GS-CMOS image sensor.
> 5320 × 3032@30 fps.
> Video compression standards: H.265, H.264M, H.264H and MJPEG.
> Works in poor lighting and does not smear.
> High-speed capture.
>Integrated design, IP66 and IK10 rated.
Camera Image Sensor 1.1″ GS-CMOS Shutter Mode Single shutter; Double shutters; Three shutters Electronic Shutter Speed Auto/Manual 1/50 s–1/100,000 s Noise Reduction 3D NR S/N Ratio 48 dB WDR 120 dB Min. Illumination 0.001 lux Day/Night ICR auto switch: Use the IR transmitting filter during the daytime and nighttime. Illuminator Illuminator Number 8 IR Light Yes Illumination Distance 23 m-30 m (75.46 ft–98.43 ft) (brightness adjustable) Lane Coverage Center mount: 5 lanes Side mount: 4 lanes
Lens Lens Type Motorized Vari-focal Focal Length 16 mm–40 mm Max. Aperture F1.4 Iris Type P-Iris Field of View Horizontal: 21.4°–50.6°
Vertical: 12.3°–28.9°
Diagonal: 24.4°–58°Function Trigger Mode Video trigger/Radar trigger Speed Detection Range 0 km/h–300 km/h OSD Overlay Time; address; lane No.; plate; plate color; and more Alarm Event Storage full; storage error; external alarm; no storage card; license plate blocklist; illegal access; network disconnection; IP conflict Automatic Network Replenishment (ANR) Platform and FTP (TF card is required) Auto Registration Yes Intelligence Target Detection Motor vehicle; motorcycle Face Detection Detects the driver and front-seat passenger of motor vehicles, and motorcycle drivers; extracts face images ANPR Adopts developed algorithms to recognize license plate numbers and letters Vehicle Type Recognition Vehicle head: SUV, Large bus, sedan, light truck, pickup, heavy truck, medium truck, van, medium bus, MPV Vehicle tail: SUV, large bus, sedan, light truck, pickup, heavy truck, medium truck, van
Vehicle Brand/Logo Recognition Vehicle head mode: Acura, Alfaromeo, Ashokleyland, Astonmartin, Audi, Baic, Bently, Benz, BMW, Buick, BYD, Cadillac, Chery, Chevrolet, Chrysler, Citroen, Dacia, Daihatsu, Datsun, Dodge, DS, Ferrari, Fiat, Force, Ford, Foton, Geely, GMC, Greatwall, Hino, Honda, Hyundai, Infiniti, Isuzu, Iveco, Jac, Jaguar, Jeep, Kia, Kinglong, Land, Lexus, Lifan, Lincoln, Mahindra, MAN, Maserati, Mazda, Mercury, MG, Mini, Mitsubishi, Nissan, Opel, Peugeot, Porsche, Renault, Rollsroyce, Saab, Scania, Seat, Skoda, Smart, Subaru, Suzuki, Tata, Tesla, Toyota, UD, Volkswagen, Volvo Motor Vehicle Violation Capture ANPR mode: Wrong-way driving, speeding, driving slow, crossing the solid white line, crossing the solid yellow line, illegal lane change, unfasten seat belt, calling while driving, smoking while driving Motorcycle Violation Capture Captures traffic violations including carrying passenger, not wearing helmet, and wrong-way driving Traffic Flow Detection Generates statistics on vehicle flow, queue length, average speed, lane occupancy, and more Traffic Event Motor vehicle illegal stopping on the roadway; traffic congestion Video Video Compression H.265; H.264M; H.264H; MJPEG Video Resolution 5320 (H) × 3032 (V) Video Frame Rate 50Hz: Maximum 25 fps; default main stream (4096 × 2160@12.5fps), sub stream (1600 × 1200@12.5 fps) 30Hz: Maximum 30 fps; default main stream (4096 × 2160@15 fps), sub stream (1600 × 1200@15 fps)
Video Bit Rate H.264: 32 kbps–32767 kbps H.265: 32 kbps–32767 kbps
MJPEG: 512 kbps–32767 kbps
Bit Rate Control CBR/VBR White Balance Auto; Night; Customized Color Temperature Edge Enhancement Yes HLC Yes BLC Yes Bad Pixel Correction Yes Gain Range 0-100 Image Composite Image Supports combining up to 4 images into a composite image Image Resolution 5320 (H) × 3032 (V) (OSD black strip excluded) Image Encoding Format JPEG Image Tampering Prevention Verifies watermarks in videos and images Network Network Port 2 × RJ-45 Ethernet ports, 10/100/1000 M network transmission SDK and API Yes Security Authorized username and password, MAC address binding, HTTPS encryption, and network access control Network Protocol IPv4/IPv6; HTTP; TCP/IP; UDP; NTP; DHCP Interoperability ONVIF (Profile S/Profile G/Profile T) Browser Microsoft Edge
IE: IE9–IE11
Chrome: Chrome 41 and earlier
Firefox: Firefox 49 and earlier
For Win 10 users, run the browser as administratorPositioning GPS Network Status Monitoring NTP; GPS Port Storage 1, TF card (maximum 256 GB@Class10) Iris Control 1, connects to DC auto iris or P-IRIS Focus Control 1, connects to motorized vari-focal lens Frequency Source Sync 1, supports synchronizing the camera with the mains electricity Peripheral Light 7, optocoupler signal output (can be configured as flash light or LED strobe sync output interface, frequency adjustable) USB 2 USB 3.0 Ports RS-485 2, connects to devices such as signal detector, radar, and more RS-232 4 (3 for radar connection, and 1 for serial port debugging) I/O 4, same functions as ALARM IN port Audio Input 1 channel (3.5mm JACK port) Audio Output 1 channel (3.5mm JACK port) Alarm Input 4, same functions as I/O port Alarm Output 2 (AO1 is for relay output and AO2 for optocoupler output) Power Output 12 VDC ± 10% voltage output, ≤1.5 A current output General Power Supply 100–240 VAC (50 Hz/60 Hz) Power Consumption ≤20 W Operating Temperature –40 °C to +65 °C (–40 °F to +149 °F) Storage Temperature –40 °C to +70 °C (–40 °F to +158 °F) Operating Humidity 10%–90% (RH) Storage Humidity 0%–90% (RH) Certifications CE: E234884-A6104-IT-5; 4790795807-2-1 Protection IP66, IK10 Product Dimensions 554.0 mm × 204.2 mm × 209.6 mm (21.81″ × 8.04″ × 8.25″) (L × W × H) Net Weight 4.6 kg (10.14 lb) Gross Weight 6.6 kg (14.55 lb) Installation Center mount; side mount
